BUW6-100-DSP1-D23

Name: BUW6-100-DSP1-D23
Brand: STASTO
SKU: BUW6-100-DSP1-D23
Price: 96844.0 RSD
Availability: InStock

Butterfly valve with pneumatic actuator; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner Polyurethane; Nominal flange pressure PN10/16/ANSI150; Double acting actuator; Control pressure 5,5...8bar; Medium temperature -10...+90°C; Pressure range 0...10bar; DN 100mm; Length 52mm; Actuator PAD100

Intrastat No.: 84818085
Country of origin: Italy
Weight: 11.05 Kg
Short Itemnumber: BUW6100DSP1D23

butterfly valve with pneumatic actuator; wafer type; length according to EN558−1R20; body ductile iron EN-GJS-400-15 epoxy coated; disc AISI 316; shaft AISI 430; liner polyurethane; nominal flange pressure PN10/16/ANSI150; double acting actuator; control pressure 5,5...8bar; medium temperature -10...+90°C; pressure range 0...10bar; DN 100mm; length 52mm; actuator PAD100

96.844,00 din. 96844.0 RSD 96.844,00 din.

This combination does not exist.

Availability:

Add to cart

Specifications
Spare Parts

No Specifications

BUW6-100-DSP1-B x 1.0

Butterfly valve with bare shaft BUW6-100-DSP1-B

Butterfly valve with bare shaft Series BUW6-DSP1-B; Wafer type; Length According to EN558−1R20; Body Ductile iron EN-GJS-400-15 Epoxy coated; Disc 1.4408; Shaft 1.4016; Liner Polyurethane; Nominal flange pressure PN10/16/ANSI150; Medium temperature -10...+90°C; Pressure range 0...16bar; DN 100mm; Length 52mm

Add to Cart

PAD100 x 1.0

Pneumatic actuator PAD100

Pneumatic actuator Series PAD; ATEX II 2 G/D; Double acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Diameter 100mm; Flange ISO5211 F07/F10; Female square 17mm; Torque at 5,5bar 150Nm

Add to Cart

MFFALFUAL09733 x 1.0
