Cylinders

Diameter Connection Stroke Piston rod thread Function Push force at 6 bar Type Sequence
25 mm 1/8" 25 M10x1,25 Double acting 295 N DVM25/25 20050
25 mm 1/8" 50 mm M10x1,25 Double acting 295 N DVM25/50 20052
25 mm 1/8" 80 mm M10x1,25 Double acting 295 N DVM25/80 20053
25 mm 1/8" 100 mm M10x1,25 Double acting 295 N DVM25/100 20054
25 mm 1/8" 125 mm M10x1,25 Double acting 295 N DVM25/125 20055
25 mm 1/8" 160 mm M10x1,25 Double acting 295 N DVM25/160 20056
25 mm 1/8" 200 mm M10x1,25 Double acting 295 N DVM25/200 20058
25 mm 1/8" 250 mm M10x1,25 Double acting 295 N DVM25/250 20061
PC52-12-10
Mini magnetic cylinder Series PC52; Double acting; Pressure range 1...10bar; According to DIN / ISO 6432; Diameter 12mm; Stroke 10mm; Piston rod thread M6; Connection M5; Push force at 6 bar 68N
To Series: Mini magnetic cylinder Series PC52
Diameter Connection Stroke Piston rod thread Function Push force at 6 bar Rod seal Seal Type
12 mm M5 10 mm M6 Double acting 68 N PU PU PC52-12-10
DVM12/10SEA
Mini magnetic cylinder Series DVM-SEA; Single acting; Pressure range 2...10bar; According to DIN/ISO 6432; Diameter 12mm; Stroke 10mm; Piston rod thread M6; Connection M5; Push force at 6 bar 44N
To Series: Mini magnetic cylinder Series DVM-SEA
Diameter Connection Stroke Piston rod thread Function Push force at 6 bar Type
12 mm M5 10 mm M6 Single acting 44 N DVM12/10SEA
PC52-12-15
mini magnetic cylinder series PC52; double acting; pressure range 1...10bar; according to DIN / ISO 6432; diameter 12mm; stroke 15mm; piston rod thread M6; connection M5; push force at 6 bar 68N
To Series: Mini magnetic cylinder Series PC52
Diameter Connection Stroke Piston rod thread Function Push force at 6 bar Rod seal Seal Type
12 mm M5 15 mm M6 Double acting 68 N PU PU PC52-12-15
DVM12/25SEA
Mini magnetic cylinder Series DVM-SEA; Single acting; Pressure range 2...10bar; According to DIN/ISO 6432; Diameter 12mm; Stroke 25mm; Piston rod thread M6; Connection M5; Push force at 6 bar 44N
To Series: Mini magnetic cylinder Series DVM-SEA
Diameter Connection Stroke Piston rod thread Function Push force at 6 bar Type
12 mm M5 25 M6 Single acting 44 N DVM12/25SEA
PC52-12-19
mini magnetic cylinder series PC52; double acting; pressure range 1...10bar; according to DIN / ISO 6432; diameter 12mm; stroke 19mm; piston rod thread M6; connection M5; push force at 6 bar 68N
To Series: Mini magnetic cylinder Series PC52
Diameter Connection Stroke Piston rod thread Function Push force at 6 bar Rod seal Seal Type
12 mm M5 19 mm M6 Double acting 68 N PU PU PC52-12-19
DVM12/50SEA
Mini magnetic cylinder Series DVM-SEA; Single acting; Pressure range 2...10bar; According to DIN/ISO 6432; Diameter 12mm; Stroke 50mm; Piston rod thread M6; Connection M5; Push force at 6 bar 44N
To Series: Mini magnetic cylinder Series DVM-SEA
Diameter Connection Stroke Piston rod thread Function Push force at 6 bar Type
12 mm M5 50 mm M6 Single acting 44 N DVM12/50SEA
PC52-12-20
mini magnetic cylinder series PC52; double acting; pressure range 1...10bar; according to DIN / ISO 6432; diameter 12mm; stroke 20mm; piston rod thread M6; connection M5; push force at 6 bar 68N
To Series: Mini magnetic cylinder Series PC52
Diameter Connection Stroke Piston rod thread Function Push force at 6 bar Rod seal Seal Type
12 mm M5 20 mm M6 Double acting 68 N PU PU PC52-12-20
DVM16/10SEA
Mini magnetic cylinder Series DVM-SEA; Single acting; Pressure range 2...10bar; According to DIN/ISO 6432; Diameter 16mm; Stroke 10mm; Piston rod thread M6; Connection M5; Push force at 6 bar 96N
To Series: Mini magnetic cylinder Series DVM-SEA
Diameter Connection Stroke Piston rod thread Function Push force at 6 bar Type
16 mm M5 10 mm M6 Single acting 96 N DVM16/10SEA
PC52-12-22
Mini magnetic cylinder Series PC52; Double acting; Pressure range 1...10bar; According to DIN / ISO 6432; Diameter 12mm; Stroke 22mm; Piston rod thread M6; Connection M5; Push force at 6 bar 68N
To Series: Mini magnetic cylinder Series PC52
Diameter Connection Stroke Piston rod thread Function Push force at 6 bar Rod seal Seal Type
12 mm M5 22 M6 Double acting 68 N PU PU PC52-12-22
DVM16/15SEA
Mini magnetic cylinder; Single acting; Pressure range 2...10bar; According to DIN/ISO 6432; Diameter 16mm; Stroke 15mm; Piston rod thread M6; Connection M5; Push force at 6 bar 96N
To Series: Mini magnetic cylinder Series DVM-SEA
Diameter Connection Stroke Piston rod thread Function Push force at 6 bar Type
16 mm M5 15 mm M6 Single acting 96 N DVM16/15SEA
PC52-12-25
Mini magnetic cylinder Series PC52; Double acting; Pressure range 1...10bar; According to DIN / ISO 6432; Diameter 12mm; Stroke 25mm; Piston rod thread M6; Connection M5; Push force at 6 bar 68N
To Series: Mini magnetic cylinder Series PC52
Diameter Connection Stroke Piston rod thread Function Push force at 6 bar Rod seal Seal Type
12 mm M5 25 M6 Double acting 68 N PU PU PC52-12-25
DVM16/25SEA
Mini magnetic cylinder Series DVM-SEA; Single acting; Pressure range 2...10bar; According to DIN/ISO 6432; Diameter 16mm; Stroke 25mm; Piston rod thread M6; Connection M5; Push force at 6 bar 96N
To Series: Mini magnetic cylinder Series DVM-SEA
Diameter Connection Stroke Piston rod thread Function Push force at 6 bar Type
16 mm M5 25 M6 Single acting 96 N DVM16/25SEA
