STASTO Combination

STASTO Combination

STASTO Combination
Fully assembled and tested
Consists of:
- 1 Pcs Maintenance unit FRL-12-20-08-R-PE-SS; Relieving; Drain valve Semi-automatic; Pressure range 0,5...8bar; Filter element 20µm; Plastic bowl with protection cage; Flow at 6,3bar/Δp=1bar 2200Nl/min; Max. inlet pressure 12,5bar
- Inlet:
Distributor; Connection Elbow adapter With Coupling plug DN 7,2; Number of outlets 2, With Coupling DN 7,2
- Outlet:
2-fold Coupling distributor DN 7,2

Intrastat No.: 84811005
Country of origin: Italy
Weight: 2.012 Kg
Short Itemnumber: FRA005
https://www.stasto.rs/web/image/product.template/185415/image_1920?unique=351c77c

STASTO Combination
fully assembled and tested
consists of:
- 1 pcs maintenance unit FRL-12-20-08-R-PE-SS; relieving; drain valve semi-automatic; pressure range 0,5...8bar; filter element 20µm; plastic bowl with protection cage; flow at 6,3bar/Δp=1bar 2200Nl/min; max. inlet pressure 12,5bar
- inlet:
distributor; connection elbow adapter with coupling plug DN 7,2; number of outlets 2, with coupling DN 7,2
- outlet:
2-fold coupling distributor DN 7,2

33.053,00 din. 33053.0 RSD 33.053,00 din.

cena na zahtev

  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element

This combination does not exist.

Availability:
Contact Us

Share

No Specifications
C0P72-M12-B-C
C0P72-M12-B-C x 1.0
C0P72-M12-B-C
Coupling plug DN 7,2; Male thread; Brass; Pressure -0,87...35bar; Temperature Max. 100°C; Thread 1/2"
Add to Cart
Distributor DI02-2-12
DI02-2-12 x 1.0
Distributor DI02-2-12
distributor series DI02; material anodized aluminum; outlet thread 1/2"; connecting thread 1/2"; outlets einseitig; distance of outlets 34mm; number of outlets 2
Add to Cart
C0C72-M12-B
C0C72-M12-B x 2.0
C0C72-M12-B
Coupling DN 7,2; Male thread; Brass; Seal NBR; Pressure -0,87...35bar; Temperature Max. 100°C; Thread 1/2"
Add to Cart
FR-12-20-08-R-PE-SS-X x 1.0
FR-12-20-08-R-PE-SS-X
Filter regulator; Relieving; Drain valve Semi-automatic; Pressure range 0,5...8bar; Filter element 20ym; Plastic bowl with protection cage; Connection 1/2"; Flow at 6,3bar/Δp=1bar 2880Nl/min; Max. inlet pressure 12,5bar; Without manometer
Add to Cart
Lubricator L-12-PE
L-12-PE x 1.0
Lubricator L-12-PE
Lubricator Series L; Plastic bowl with protection cage; Connection 1/2"; Flow at 6,3bar/Δp=1bar 3000Nl/min; Max. inlet pressure 12,5bar
Add to Cart
Bourdon tube manometer MA001-40R-10-D
MA001-40R-10-D x 1.0
Bourdon tube manometer MA001-40R-10-D
Bourdon tube manometer Series MA001; Body Sheet steel; Measuring unit, Motion work Copper based alloy; Front glass Acryl; Ambient temperature -20...+60°C; Medium temperature Max. +60°C; Connection Rear; Class 1,6; Diameter 40mm; Indicating range 0-10/0-145; Unit bar/psi; Connection 1/8"
Add to Cart
C0C72-M12-B
C0C72-M12-B x 2.0
C0C72-M12-B
Coupling DN 7,2; Male thread; Brass; Seal NBR; Pressure -0,87...35bar; Temperature Max. 100°C; Thread 1/2"
Add to Cart
