PRT-002

PRT-002

STASTO Combination consists of:
3-fold solenoid valve unit
3 Stk.5/2-way valve; pilot-operated; pressure range 2,5...9bar; actuation electrical/spring; nominal diameter 8mm; flow rate 1300Nl/min; incl. coil and connector 230VAC;
inlet base plate 8mm;
outlets valves 6mm
fully assembled and tested

Intrastat No.: 84812090
Country of origin: Italy
Weight: 1.246 Kg
Short Itemnumber: PRT002
https://www.stasto.rs/web/image/product.template/220831/image_1920?unique=8d26980

STASTO Combination consists of:
3-fold solenoid valve unit
3 Stk.5/2-way valve; pilot-operated; pressure range 2,5...9bar; actuation electrical/spring; nominal diameter 8mm; flow rate 1300Nl/min; incl. coil and connector 230VAC;
inlet base plate 8mm;
outlets valves 6mm
fully assembled and tested

67.257,00 din. 67257.0 RSD 67.257,00 din.

cena na zahtev

excl. tax
  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element
  • Brand

This combination does not exist.

Availability:
See availability
Contact Us

Technical specifications

Brand STASTO
Brand STASTO
Manifold sub-base KME314
KME314 x 1.0 Pcs
Manifold sub-base KME314
Manifold sub-base Series K; For way-valves Series K5., K6., K9.; Anodized aluminum; Number of valves 3; Pressure connection 3/8"; Exhaust ports 3/8"; Valve size 1/4"
K52W1014-CS23050-6-14423-0528
K52W1014-CS23050-6-14423-0528 x 3.0 Pcs
K52W1014-CS23050-6-14423-0528
K52W1014 5/2-way valve Series K5.W; Pilot-operated; Pressure range 2,5...9bar; Actuation Electrical/spring; Type of coil CS; Connector size 16mm; Connection 1/4"; Nominal diameter 8mm; Flow rate 1300Nl/min; Suitable silencer alle CS23050 Coil Type CS; Connector size 16mm; Voltage 230V/50-60Hz 6-14423-0528 Connector; Connector size 16mm; With integrated LED-yellow and VDR; Voltage 230VAC/DC
Plug screw TH50-38-N-0
TH50-38-N-0 x 3.0 Pcs
Plug screw TH50-38-N-0
Plug screw Series TH50; Nickel plated brass; With o-ring NBR; Cylindrical thread; Hexagon socket; Thread 3/8"
Silencer SLN-M38-RB
SLN-M38-RB x 2.0 Pcs
Silencer SLN-M38-RB
Silencer Series SLN-RB; Sinterbronze; Thread Steel copper plated; Operating pressure Max. 16bar; Connection 3/8"; Length 36mm
Unidirectional banjo flow control valve UFC05-V-14-06
UFC05-V-14-06 x 4.0 Pcs
Unidirectional banjo flow control valve UFC05-V-14-06
Unidirectional banjo flow control valve Series UFC05-C/V; Push-in fitting-banjo; Actuation Slotted screw/Knurled screw fixable; Connection 1/4"; Diameter Hose 6mm; Direction of flow control From hose to thread (ingoing air)
