Flanged ball valve with pneumatic actuator BA043-32-S0-01

Flanged ball valve with pneumatic actuator BA043-32-S0-01

Flanged ball valve with pneumatic actuator Series BADA; Flange PN16; Body Steel; Ball 1.4301; Seals PTFE/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...16bar; Nominal diameter 32mm; Length 54mm; Actuator PAS0855

Intrastat No.: 84818081
Country of origin: Italy Made in Europe
Weight: 7.91 Kg
Short Itemnumber: BA04332S001
https://www.stasto.rs/web/image/product.template/188310/image_1920?unique=bc71d62

flanged ball valve with pneumatic actuator series BADA; flange PN16; body steel; ball AISI 304; seals PTFE/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; pressure range 0...16bar; nominal diameter 32mm; length 54mm; actuator PAS0855

72.850,00 din. 72850.0 RSD 72.850,00 din.

cena na zahtev

excl. tax
  • DN
  • Length
  • Pressure range
  • Actuator
  • Brand

This combination does not exist.

Availability:
See availability
Contact Us

Technical specifications

Pressure range 0...16 bar
DN 32 mm
Length 54 mm
Brand STASTO
Pressure range 0...16 bar
DN 32 mm
Length 54 mm
Brand STASTO
Flanged ball valve 722000-32
722000-32 x 1.0 Pcs
Flanged ball valve 722000-32
Flanged ball valve Series 722000; Flange PN16, Full bore; Body Steel; Ball 1.4301; Seals PTFE/FKM; Pressure range 0...16bar; Medium temperature -20...+160°C; Nominal diameter 32mm; Length 54mm
Pneumatic actuator PAS0755
PAS0755 x 1.0 Pcs
Pneumatic actuator PAS0755
Pneumatic actuator Series PAS; ATEX II 2 G/D; Single acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Diameter 75mm; Flange ISO5211 F05/F07; Female square 17mm; Torque at 5,5bar 17,5Nm
RI3048 x 1.0 Pcs
RI3048
Mounting bracket; F05-F04/03; Bolt 14-8
Accessory Products
EB0X01
EB0X01
Material of case
Plastic
Brand
STASTO
EB0X02
EB0X02
Material of case
Plastic
Brand
STASTO
EB0X04YA
EB0X04YA
Material of case
Aluminum
Brand
STASTO
EB0X04YA-ULCSA-01
EB0X04YA-ULCSA-01
Material of case
Aluminum
Brand
STASTO
EB0X05
EB0X05
Design
ATEX
Material of case
Plastic
Brand
STASTO
RI4605
RI4605
Diameter
75 mm
RI4619
RI4619
Diameter
75 mm
RI4647
RI4647
Diameter
75 mm
