Flanged ball valve with pneumatic actuator BA045-32-S0

Flanged ball valve with pneumatic actuator BA045-32-S0

Flanged ball valve with pneumatic actuator Series BA045-S0; Flange PN40; Body Steel; Ball 1.4301; Seals PTFE-reinforced/FKM; Single acting actuator; Control pressure 5,5...8bar; Medium temperature -20...+160°C; Pressure range 0...40bar; Nominal diameter 32mm; Length 54mm; Actuator PAS0855

Intrastat No.: 84818081
Country of origin: Italy
Weight: 9.31 Kg
Short Itemnumber: BA04532S0

flanged ball valve with pneumatic actuator series BA045-S0; flange PN40; body steel; ball AISI 304; seals PTFE-reinforced/FKM; single acting actuator; control pressure 5,5...8bar; medium temperature -20...+160°C; pressure range 0...40bar; nominal diameter 32mm; length 54mm; actuator PAS0855

77.926,00 din. 77926.0 RSD 77.926,00 din.

excl. tax

Valve interface Namur
- -
DN
- 50 mm
Length
- 82 mm
Connector size
- -
Design
- -
Voltage
- -
Pressure range
- 0...16 bar
Coil
- -
Actuator
- PAS1005

This combination does not exist.

Availability:

See availability

Technical specifications

Pressure range	0...16 bar
DN	50 mm
Length	82 mm

Specifications
Spare Parts

Pressure range	0...16 bar
DN	50 mm
Length	82 mm

Flanged ball valve BA045-32-L

BA045-32-L x 1.0 Pcs

Flanged ball valve BA045-32-L

Flanged ball valve Series BA045; Flange PN40, Full bore; Body Steel; Ball 1.4301; Seals PTFE-reinforced/FKM; Pressure range 0...40bar; Medium temperature -20...+160°C; Nominal diameter 32mm; DN ball 54mm

Pneumatic actuator PAS0855

PAS0855 x 1.0 Pcs

Pneumatic actuator PAS0855

Pneumatic actuator Series PAS; ATEX II 2 G/D; Single acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Diameter 85mm; Flange ISO5211 F05/F07; Female square 17mm; Torque at 5,5bar 28,7Nm

RI3030 x 1.0 Pcs

RI3030

Mounting bracket; F05/F03-F04,11-8

Square adapter VK1711

VK1711 x 1.0 Pcs

Square adapter VK1711

Square adapter Series VK; 17X11; Length 16mm; Material Stahl

Accessory Products

EB0X01

Material of case: Plastic

Brand: STASTO

EB0X02

Material of case: Plastic

Brand: STASTO

EB0X04YA

Material of case: Aluminum

Brand: STASTO

EB0X04YA-ULCSA-01

EB0X04YA-ULCSA-01

Material of case: Aluminum

Brand: STASTO

EB0X05

Design: ATEX

Material of case: Plastic

Brand: STASTO

RI4606

Diameter: 85 mm

RI4620

Diameter: 85 mm

RI4648

Diameter: 85 mm
